Description
*This product is reaching end-of-life and will soon be discontinued. Visit Impinj RHCP Far Field RFID Antenna (FCC/ETSI) for a recommended replacement product.*
Impinj Threshold (LP) Indoor RFID Antenna (FCC)
Initially designed for boundary/threshold crossing applications, the Impinj Threshold antenna has a very wide beam width to maximize zone coverage. Threshold antennas provide a consistent and continuous read zone when linearly distributed head- to-tail. At 46 x 9 x 2 cm, the Threshold antenna’s planar form factor fits readily onto fencing or other borders.
Data Sheet — Impinj Threshold (LP) Indoor RFID Antenna
Need help selecting the right antenna? Check out our antenna guide.
What's included?
- Impinj Threshold Antenna Unit
- One 2 Meter Antenna Cable (LMR-195, RP-TNC Male to SMA Male)
Why buy this antenna?
The Impinj Threshold RFID Antenna has a 100 degree vertical plane beamwidth which makes it ideal to be integrated into doors or fences.
Features
- Strong far-field performance.
- Wide beam width to maximize zone coverage.
- Low profile form factor of 457 x 89 x 19 mm.
- Optimized performance for operation from 902–928 MHz.
Information
We can supply you with ANY length custom cable with ANY type of connectors. If you don't see the cable you need, please contact us so we can assist you.
Video
| Product Type: | Antenna |
|---|---|
| ELECTRICAL: | |
| Operating Frequency: | FCC (902-928 MHz) |
| Polarization: | Linear |
| Gain: | 5.0 dBi |
| Max Read Distance: | Not published |
| Elevation Beamwidth: | 120°± 3° |
| Azimuth Beamwidth: | 60°± 3° |
| MECHANICAL: | |
| Connector Type: | SMA Female (connects to SMA Male) |
| Cable: | 2 m (6.6 ft) antenna cable (LMR-195, RP-TNC Male to SMA Male) |
| Mounting: | Not published |
| Dimensions: | 457 x 89 x 19 mm (17.99 x 3.50 x .75 in) |
| Weight: | 0.68 kg (1.5 lbs) |
| ENVIRONMENT: | |
| IP Rating: | IP 54 |
| Operating Temperature: | -25° to 55°C (-13° to 131°F) |
