Description
Impinj Speedway Antenna Hub
Impinj Speedway Antenna Hub
The Impinj Speedway Antenna Hub provides a low-cost opportunity to drive many antennas from a single fixed RAIN RFID reader. This antenna hub connects up to 32 antennas to a single Impinj Speedway R420 reader, up to 16 antennas to a single Impinj Speedway R220 reader (reader must be updated to the Firmware Version 7.6), and up to 8 antennas to a single Impinj Speedway R120 reader. The Speedway Antenna Hub makes RFID monitoring applications requiring many antennas, including large contiguous read zones and smart shelves, cost-effective, and easy to deploy.
NOTE: This hub comes standard with different connectors than Impinj readers and requires a separate purchase of cables to connect a compatible reader and up to 8 antennas per hub. Contact us today for recommended products.
Data Sheet — Impinj Speedway Antenna Hub
Quick Start Guide — Impinj Speedway Antenna Hub
What's included?
- Impinj Speedway Antenna Hub Unit
Why buy this antenna hub?
Users will benefit from fast, hassle-free installation and deployment with the Speedway Antenna Hub solution which includes antenna virtualization software, GPIO adapter, and an enclosure with LEDs for system feedback.
Features
- Hassle-free operation when connected to a single high-performance Speedway Revolution reader and GPIO Adapter.
- Robust and easy to install design with system level feedback for reliable installations in real world conditions.
- Enclosed electronics board with mounting tabs.
- LEDs for system level feedback.
- Software alerts/health diagnostics.
- All of the performance benefits of the Speedway Revolution reader without the need to learn a new API or make extensive programming changes.
- With the Speedway Antenna Hub, Impinj makes RFID monitoring applications, including smart shelves, interactive marketing displays, and document or item tracking, cost-effective, and easy to deploy.
Compatibility
- Impinj Speedway Revolution R120 UHF RFID Reader - 1 Port
- Impinj Speedway Revolution R220 UHF RFID Reader - 2 Port (Reader must be updated to Firmware Version 7.6)
- Impinj Speedway Revolution R420 UHF RFID Reader - 4 Port
Note: The Impinj Speedway Antenna Hub is NOT compatible with the Impinj R700 RAIN RFID Reader.
Videos
| Product Type: | Fixed Reader Accessory |
|---|---|
| ELECTRICAL: | |
| Frequency: | Global (860-960 MHz) |
| Power Supply: | 5V provided by the GPIO Adapter if selected above |
| Insertion Loss: | 1.3 dB (Max) |
| Return Loss: | 24 dBm (Min) |
| GPIO: | 1 Digital I/O: RJ45 |
| MECHANICAL: | |
| Dimensions: | 102 x 61 x 24 mm (4 x 2.4 x 1 in) |
| Weight: | 0.1 kg (0.2 lbs) |
| Connectors: | RF Input: SMA female (connects to SMA male), 8 RF Outputs: SMA female (connects to SMA male) |
| Mounting Options: | Two 1/4 in mounting holes |
| Antenna Port Numbering: | 1-32 on Antenna Hubs; 1, 9, 17, 25 on native ports |
| ENVIRONMENT: | |
| IP Rating: | IP 52 |
| Operating Temperature: | -40 °C to +80 °C (-40 °F to +176°F) |
