Description
*Formerly sold under the brand Confidex. This is the same great tag - just with a new name.*
Beontag Captura Flash RFID Tag | NXP UCODE 8m
Beontag Captura Flash RFID Tags present unprecedented level in both RFID tag security and usability. These tags come with both mechanical and electrical seal functions and are extremely easy and fast to attach. When required, Beontag Captura Flash tags can be encoded and equipped with a barcode, printing, or branding according to the project requirements. Beontag Captura Flash tags provide reliable identification in RFID gates by giving 12 m read range in optimal use case. Combined with tamper-proof antenna design structure and NXP UCODE8m with the option of adding a brand identifier, Beontag Captura Flash is the choice for securing your asset's ID.
Data Sheet — Beontag Captura Flash RFID Tag | NXP UCODE 8m
Need help selecting the right tag? Check out our tag guide.
Why buy this tag?
Designed to be attached fast and easy without any tools, Beontag Captura Flash RFID Tags are durable tamper-proof seal tags ideally suited for manufacturing, automotive, and logistics applications.
Features
- IP 68 rated.
- Tamper-proof antenna and seal functionality.
- Cost-efficient brand authentication.
- Up to 12 m (39 ft) read range in optimal use cases.
- Optimized for metal.
- Branding available with printable, protected label inside.
- Option for extra security: brand identifier with the NXP IC UCODE 8m.
- Common applications: asset management, logistics and supply chain, industrial manufacturing, and automotive.
| Product Type: | Tag |
|---|---|
| ELECTRICAL: | |
| Air Interface Protocol: | EPCglobal UHF Gen2v2 |
| Operating Frequency: | Global (865‐928 MHz) |
| IC Type: | NXP UCODE 8m |
| Memory: | EPC 96 Bit, User 32 Bit, TID 96 Bit |
| EPC Memory Content: | Unique Number Encoded as a Default |
| Max Read Distance (Hanging from Metal): | Up to 12 m (39.4 ft) |
| Max Read Distance (Hanging from Plastic): | Up to 3 m (9.8 ft) |
| Max Read Distance (Hanging from Cable): | Up to 2 m (6.6 ft) |
| Applicable Surface Materials: | All Surfaces, Optimized for Metal |
| MECHANICAL: | |
| Tag Form Factor: | Seal Tag |
| Tag Materials: | High-Quality Engineering Plastics |
| Recommended Ribbon: | Not Published |
| Attachment Method: | Snap the Tag to the Attachment (Maximum 12 mm Diameter) |
| Dimensions: | 61 x 20 x 10 mm (2.4 x 0.79 x 0.39 in) |
| Weight: | 6 g |
| ENVIRONMENT: | |
| Operating Temperature: | ‐35° to +85°C (‐31° to +185°F) |
